LINKS LIGHTING OPERATORS
WITH SHOWLASERS
IN REAL TIME
“Laser like a moving-light!”
Laserlink is the independent “DMX to Laser” tool to provide the light programmer and designer with real-time results that he can work with effectively.
Without additional interfaces the laser is controlled like a moving light with a variety of options. Similar to a moving light control there are gobo channels, pan, tilt, color control and many more options for brilliant laser effects. You no longer have to deal with the speciality of lasers and you can start working intuitively. Finally!
The output has very high resolution and its precision is leading edge of industry. Of course, attention was also paid to safety functions such as audience horizons at any angle and safety zones. The system is ideal for live applications and complex light shows.
Laserlink is fully integrated into Depence2 without need for additional software or hardware which makes pre-production faster and predictable.
Laserlink has capabilites to run stand alone for e.g. logo projections without any need for DMX inputs. Several parameters like rotation along all axes can be run in auto mode.
REALTIME PROCESSING
DMX/ARTNET-CONTROL
REAL 16-BIT RESOLUTION
2 INDIVIDUAL OUTPUTS / MULTI OBJECTS
ULTRA COMPACT
RDM-CAPABLE
TOUCHSCREEN
EASY AS A MOVING LIGHT
OUTPUT / INTERFACES
- 2 Channels Each 16-Bit Additive Color RGBO
- 2 Channels Each 16-Bit X- And Y- Scanner Output
- 10-30K (More On Request)
- SDXC Card Reader
- DMX, RDM And ARTNET Control
- Shutter Output Signal
- Firmware Update Via Ethernet
- Gobo Upload
- DMX Synchronization
- Depence2 Visualization
- Truly Standalone Operation (No Other Devices Like Computer Or DMX-Device Needed)
DMX Channels:
- 1 x ILDA Port: 64 DMX Channels
- 2 x ILDA Port: 128 DMX Channels
- Fixtures For Grandma-Series, HOG-Series And
- Various Other Lighting Consoles Available
FEATURES
- Safety Channel
- Service Channel For Soft-Edge And Clip-Edge Effects
- Various Built In Gobos
- 16-Bit Dimmer
- 16-Bit Pan/Tilt
- 16-Bit Rotations (X,Y,Z)
- 16-Bit Zoom
- Shutter/Strobe
- 2 Independent Colorprograms With Various Patterns
- Color Crossfade
- Real Time Waves
- Various Real Time Modifiers For Transformations And Effects
- Invert X-Scanning, Invert Y-Scanning
CALIBRATIONS
- Advanced B-Spline Color Adjustments For
Thresholds And Maximum Power to achieve
Optimal White Balance And Fadings - Standard Geometric Correction (3×3)
- Adjustable Interpolation
- XY-Scanner Swap
- Adjustable Minimum Zoom
- Adjustable Horizont Functions
- Adjustable X/Y Offset
- Adjustable Clipping Mask
- Adjustable Output Offset
- Adjustable Output Size
- Adjustable Frequency
